Copper Clad Aluminum Wire (CCA Wire)

  • Copper Clad Aluminum Wire (CCA Wire)

  • Copper clad aluminum wire (CCA) is known as a conductive wire made of an aluminum core covered with a copper layer of CU purity reaching 99.9%. As the CCA wire possesses the characteristics of both copper and aluminum, this combination provides the conductive wire with optimum properties of both metals, while the wire features less weight than solid copper wire and higher electrical conductivity than pure aluminum wire, so that the composite wire is ideally suited to electrical applications where weight reduction and conductivity are highly required. Huawang CCA wire is manufactured in compliance with requirements of ASTM B566-93 standard.

CCA wire diameter: 0.08mm – 8.0mm
Standards: SJ/T 11223-2000, ASTM B 566-93

Advantages of CCA Wire
  • At the same weight and diameter, the length of copper clad aluminum wire is 2.6-3.2 times than that of pure copper wire. In other words, 1 ton of CCA wire is equivalent to 2.6-3.2 tons of pure copper wire, this incurs a much lower cost in the field of cable production and offers higher profits to manufacturer who sells related products.
  • Potential theft of CCA wire is less likely compared to pure copper wire, scrap value is almost zero since it is difficult to separate copper from aluminum.
  • Unlike the aluminum that is prone to oxidation, CCA wire has better conductivity and oxidation resistance, and easy to process.
  • The reduced weight of copper clad aluminum provides great convenience in transportation and installation and reduces shipping expenses.
  • CCA wire saves a lot of raw copper resources, helping balance out the copper supply worldwide.
Applications

Copper clad aluminum wire features a wide range of usages such as television distribution and signal transmission, can be made into welding cable, control cable and signal cable.

High Frequency Signal Transmission Cable
  • Conductor of coaxial cable for television signal distribution
  • Conductor of 50Ω RF cable
  • Conductor of flexible RF coaxial cable
  • Conductor of various data cables
  • Conductor of micro coaxial cable
Power Transmission Cable
  • Conductor of power cable
  • Conductor of control cable
  • Conductor of automotive cable
  • Conductor for building wiring
  • Busbars
  • Fuses
  • Enameled wires
Specialty Magnet Wire Coils and Windings
  • Electronic computers
  • Mobile communications devices
  • Aircraft and military instruments
Technical Parameters
  Cladding CCA Plating CCA
Class 10H (10% copper, hard-drawn) Class 10A (10% copper, annealed) Class 15H (15% copper, hard-drawn) Class 15A (15% copper, annealed)
Diameter (mm) 0.15-8.0 0.15-8.0 0.08-8.0 0.08-8.0 0.10-6.0
Copper by Weight (%) 25-31 25-31 32-40 32-40 6-15
Tensile Strength (Mpa) ≥152 110-172 ≥152 110-172 90-120
Elongation (%) 1 5 1 5 5
Conductivity (%) 62 62 64 64 62
DC resistivity (Ω.mm²/m) 0.02743 0.02743 0.02679 0.02676 0.02743
Density (g/cm³) 3.32 3.32 3.63 3.63 2.85

Huawang copper clad aluminum wire can be tailored to your specific needs.
Spool size: DIN 130, DIN 160, DIN 185, DIN 200, DIN 250, DIN 400, DIN 500, DIN 630, DIN 780;

Founded in 2006 as a metal wire manufacturer, Huawang specializes in engineering and manufacturing a broad range of bimetallic compounds that can be used as various types of composite conductors in electrical and electronics industry. Our extensive portfolio of specialty wires includes magnet wire, bare wire, stranded wire, busbar, etc. We have deep passion and aim to be associated with customers who are looking for cable conductors, coil wires, winding wires, or lead wire for their electronic components.

Capability
  • Capability

  • Huawang offers a broad range of high quality wires and raw materials including bare wire, busbar, stranded wire, tinned wire, silver plated wire, enameled wire, copper clad aluminum, copper clad steed, etc. We have a large inventory of wires of various specifications for quick delivery. Besides, we can also respond quickly with products tailored to your specific needs.
